MX8360J（降压IC）

1 Features

* Wide input voltage Range: 4V~30V

* Adjustable Output Voltage from 0.8 V to VIN

* Low RDS(ON) Switches 22mΩ /12 mΩ

* Switching Frequency ADJ

* PFM and Forced PWM Mode Selectable

* Duty Cycle up to 100%

* Short Circuit Protection

* Over Current Protection

* Internal Soft Startup

* Thermal Shutdown Protection

2 Applications

* Car Charger

* Rechargeable Portable Devices

* Type-C Docks/Adapters

* General Purpose Point-of-Load (POL)

3 Description

The MX8360J is a monolithic IC designed for a step-down DC/DC converter with low EMI signature, and own the ability of driving a 6A load without additional transistor. It saves board space. The MX8360J also can run at 100% duty cycle for low dropout operation, and Internal soft-start results in small inrush current extending battery life in portable systems. As a protection function, it has cycle by cycle peak current limit function, short protection function, thermal shutdown function and UVLO. The device is available in a 8-pin small profile ESOP8 package.
