1.2MHz，5V 2A输出电流，升压转换器XR9213

General Description

The XR9213 is a high efficiency current-mode boost converter with a fixed operation frequency. The XR9213 has been integrated a very low Rds-on NMOSFET to reduce power loss and achieve high efficiency. The maximum efficiency is up to 93%. XR9213 can output 2A current when VIN is higher than 3.6V and output is 5V. 1.2MHz operation frequency minimizes L

and C value, and internal compensation network reduces external component counts. SOT23-6 package provides the best

solution for PCB layout area.

Features

· Up To 5V-2A Output Current

· 1.2MHz Switching Frequency

· Low RDS(ON): 68mΩ

· Up to 93% Efficiency

. Over Voltage Protection

· Under-Voltage Lockout Protection

· Over-Temperature Protection

· Internal Soft Start

· 1uA Shutdown Current
