反响速度快，带防过充，上电瞬间没有尖峰电压的稳压LDO

发布时间：2023-01-09 11:32:00来源：http://www.szxunrui.cn/news907101.html

反响速度快，带防过充，上电瞬间没有尖峰电压稳压LDO,TX573XXM

一、Features

?Low power consumption

?Low voltage drop

?Low temperature coefficient

?High input voltage (up to 15V)

?Output voltage accuracy: tolerance ±2%

?SOT23, SOT23-3 ,SOT89 and TO92 package

二、Applications

?Battery-powered equipment

?Communication equipment

?Audio/Video equipment

三、General Description

The TX573XXM series is a set of three-terminal low power high voltage regulators implemented in CMOS technology. They allow input voltages as high as 15V. They are available with several fixed output voltages ranging from 2.1V to 5.0V. CMOS technology ensures low voltage drop and low quiescent current. Although designed primarily as fixed voltage regulators, these devices can be used with external components to obtain variable voltages and currents.
