3.5A, 3.0-15.0V 单通道H桥驱动芯片SA8339

Description

The SA8339 is one channel H-Bridge driver IC, it provides integrated motor-driver solution for toys, robotics, consumer products and other low voltage or battery-powered motion control applications.

The SA8339 maximum operational voltage is 15.0V. It can supply up to 3.5A of output continuous current and 6.0A of output peak current. There is internal shutdown function for over-temperature protection and over-current protection (IOCP = 6.0 A).

Package material is Pb-Free Product & RoHS compliant for the purpose of environmental protection and for sustainable development of the earth.

Features

* Operation voltage up to 15.0V

* Continuous current output up to 3.5A

* Peak current up to 6.0A

* RDSON: 110mΩ (HS+LS)

* Support PWM control

* Over current protection

* Over temperature protection

* UVLO protection

* Low standby current

* Low quiescent current
